TKM11
MULTSEA
| Quantity: | |
|---|---|
The TKM11 11KW screw air compressor combines permanent magnet technology with variable speed operation. This configuration allows motor speed to respond to changing air demand within the system's operating range. Actual energy consumption depends on operating conditions and equipment configuration.
The TKM11 is available in the following pressure configurations according to the product specification sheet:
0.8 MPa: 1.8 m³/min
1.0 MPa: 1.1 m³/min
1.25 MPa: 1.1 m³/min
Customers should verify the final model-specific performance data when confirming their order.
The listed TKM11 dimensions are 1050 × 700 × 1135 mm, with a machine weight of 265 kg. The compressor uses air cooling and is listed for an ambient temperature range of -5°C to +45°C. Allow sufficient clearance for ventilation and routine maintenance.
MULTSEA offers a broader screw air compressor range covering multiple power ratings and pressure configurations. Buyers can discuss their required airflow, pressure, electrical supply and installation conditions to determine the most suitable model.
For distributors and commercial buyers, MULTSEA supports inquiries about wholesale quantities, product specifications and available configurations. Providing complete technical requirements helps ensure that the selected 11KW PM VSD screw air compressor matches the intended application.
